©2020 EMS Ltd. All rights reserved. Page 37 of 80 MK067-0001-99 (Issue 1) 04/11/2020 AJM
SYSTEM SETUP
View System Status
Maintenance/Test
Device Options
WZM Settings
Panel Type
Sounder Options
Device Indicator
Conventional
Addressable
Conventional
Addressable
Addressable Panel
Selected
Set the panel type
Default panel type is ‘Conventional’. If the WZM is to be
connected to a conventional type fire panel, skip this section.
Otherwise, to change the panel type to ‘Addressable’, from
access level 3 (refer to the ‘Access level 3’ section for details),
press the button until the screen displays:
Press the button and the screen will display:
Press the button and the screen will display:
Press the button and the screen will display:
Press the button and the screen will display:
To Next Page
