System setup introduction

This system setup section will show you how to configure the WZM and connect it to a fire alarm panel. The

‘at WZM’ (via power-up) method of adding devices to the WZM will be used. For advanced programming,

refer to the ‘Panel Menus’ section of this document.

Important system setup notes

The installation must conform to applicable local installation codes and should only be

installed by a fully trained competent person.

SmartCell devices contain electronics that may be susceptible to damage from Electro

Static Discharge (ESD). Take appropriate precautions when handling electronic boards.

The procedures outlined in this installation guide must be carefully followed.

Always select an appropriate device type for the application as per local codes of practice,

or as advised by a qualified professional.

Side cover removal

The following steps illustrate how to remove the side covers:

Slide the side cover sideways,

creating a gap as shown.

Press the cover’s releasing clip

with your thumb (A), and

simultaneously rotate the side

cover anti-clockwise (B), as

viewed overhead to remove the

cover.

Position your fingers behind

the cover’s protruding edge.

1. 2. 3.

(A)(A)

(B)

To ensure correct operation, products must be used within the specified environmental

operating conditions.

EMS SmartCell Programming Guide
