WZM MENUS
Signal level test
This mode of operation allows the signal strength of a single device on the system or all devices globally on
the system to be indicated via the devices on board LEDs. The signal strength level is shown by flashing the
individual devices LED to ascertain the devices signal strength level. This is split into two colours :- green for
‘GOOD’ signal and red for ‘LOW’ signal. The signal strength status LED would update periodically to allow an
updated reading to be shown.
View all devices
When entered the screen will show the current settings for the devices on the system. The device listings
can be scrolled through by using the and buttons.
1
3
Attribute type
Address number
Device Display Text
O/P 1 OFF
O/P 2 OFF
Default setting
Next available address number on system
The device type followed by the devices unique ident number
(where xx = represents the ident number of the device)
Reset
Reset
Dual input / output device
To Next Page
