3.2.3.1 Loading the Carrying Case
GENERAL: Place the components in the carry case at the designated locations depicted below (Fig. 1).
NOTES:
1) The printer power supply/charger, and Ethernt to RJ11 cable should be placed in the lower slot,
before the printer is put in place, as shown in the images to the left of the case.
2) The P100 power cord, for the P100 power supply/charger, should be placed in the P100 Charger
opening, and then the power supply/charger block, as shown in the images to the right of the case.
3) Assure the P100 is powered off before closing the carrying case lid!
Fig. 1 - P100 Component Placement
