C.4 Remote Exhaust Kit
The P100 may be used for monitoring of locations where it is not desirable to have the HEPA filtered
exhaust of the unit at the test location (e.g., LAF Hood, Isolator, Filling Line, Top of Cart of Bench, etc.).
As such, it is possible to exhaust the P100 remotely using the P100 Remote Exhaust Kit
(P100.RMTEXH.KIT), depicted below. Which includes an exhaust port adapter, and 6 feet (1.8 m) of
exhaust tubing (which may both be autoclaved, or chemically sanitized, as required). Longer lengths of
tubing may be used, but it is to be noted that the longer the length the tubing, the more impact to unit run
time, when operated from battery power, will be noted. The exhaust adapter is a fairly open design, and
maximizes unit run time possible when using this option.
NOTE: If smaller ID tubing is used, this will greatly impact the battery run life of the P100. The
supplied tubing may be autoclaved as well.
For use:
1) Simply thread the exhaust adapter into the exhaust port on the P100. This should be finger tight only. Tools
shoot not be used, or needed, to attach, or detach the fitting. Note, the nut, retaining the tubing, can be
threaded off first, and the male/male fitting can be attached to the exhaust port, and then the exhaust tubing/nut
assembly can be threaded into the P100 adapter fitting. This may be found to be an easier procedure for
attachment.
2) With the exhaust fitting/tubing attached place the other end of the exhaust tubing at the desired exhaust location
(e.g., below cart level, outside of the ISO 5 zone (e.g., LAF Hood, Isolator, etc.)
