Section 1 Specifications
P100 Air Sampler Controller
Motor Type
Blower Motor
Display/Interface
Two Color LCD with Touch Screen (Blue on White), CPU
Current Firmware Version
1.083, 1.092 (or later versions, until otherwise revised)
Sample Time/Volume
Variable (User Defined), Maximums: 120-minutes/3396 Liters* @ 28.3 LPM, 30-min/3000L @ 100 LPM
Delay/Hold Times
Variable (User Defined)
Sample Flow Rates
28.3 or 100 liters per minute (LPM), or 1 cubic feet per minute (CFM)
NOTE: Requires separate inlet covers for the 28.3 (1 CFM) and 100 LPM Sample Rates
Flow Rate Control
Electronic, Closed-Loop, Mass-Flow Control
Test Media (Plates)
Size: 90mm Test Plates (Plastic Petri Dishes) Fill Height: 15 to 50ml (standard to double, or high fill plates)
Printer (Optional)
Thermal Label or Paper
Control System (CPU)
Microprocessor Controlled (32bit PIC Processor)
Memory
512kb Flash Program , 128kb RAM Data, 1mb Sample Runs, 512kb EPROM Calibration Set Points
Unit Equipment ID/Number
User Defined/Selectable
Site Descriptions
User Created/Deleted/Selectable
Program Descriptions
User Created/Deleted/Selectable (Includes: Sample Rate, Volume/Time, Flow/Volume Units, Delay/Test/Hold)
Sample ID
Unique System Generated (Unit Serial # + 5 digit string)
Input/Output
USB Client 1.1, Ethernet 10BaseT-/100-BaseT
Audible Alarm
Internal (with User Volume Control)
Alarms
Flow Alarm +5% (On/Off)
Dimensions
LxWxH: 7.5 x 5.5 x 6.5 inches (190 x 134 x x 165 cm)
Enclosure Materials
Inlet Base & Base Cover: 6061 Aluminum (Clear Anodized) / Cover: Kydex
TM
with Microban
TM
/ Handle: Aluminum
Inlet Cover Materials
6061 Aluminum, 28.3 LPM (1 CFM) Inlet Clear Anodized, 100 LPM Inlet Blue Anodized, 300 Holes/Inlet Cover
Exhaust Filter
HEPA Filter, 0.2 micron, Replaceable
Weight
5.4 Pounds 2.5 Kilograms
Tripod Mount
Bottom Cover, ¼-20 Threading x 0.250” (6.4 mm) Depth
Battery Pack
8 Cell Lithium Ion, 4400mAh, 14.8V
AC/DC Power Supply
Input: 100-240 VAC, 50/60 Hz,130VA-168VA 1.4 AMPS / Output: DC 18V 3.6A
Battery Charging/Life
Full Battery Charge from Full Discharge: Approximately 2.5 hours
Battery Life: Approximately 10 Hours @ 28.3 LPM & 6 Hours @ 100 LPM
Operating Range
5-40º C, 10-80% RH, non-condensing*; Indoor Use; Max Altitude 6560 feet (2000 meters)
*Note: As temperature increases from 30 to 40º C, humidity range drops from 80 to 50% linearly.
Calibration
Flow Rate (28.3/1 CFM and/or100 LPM)
Calibration Frequency
User Defined (Recommended every 6-12 months)
Verification
Sample Timer
Verification Frequency
User Defined (Recommended every 6-12 months)
Gas Compatibility
Air and inert gases such as carbon dioxide, nitrogen, and argon
Installation Category
Category 1
Pollution Degree
1 and 2
