4.4 Electrical/Data Connections
English
DANGER
Electric shock hazard. Always disconnect power to the instrument when making electrical
connections.
Français
DANGER
Un choc électrique risque. Toujours couper l'alimentation de l'instrument lors des branchements
électriques.
Fig 4.3.1
P100 Rear/Side View
Connections:
1. DC Input Port: AC/DC Power Supply (Battery Charging, Power Connected Operation)
2. USB Port: Data Output to USB stick, firmware updates
3. Ethernet Port: Calibration, Optional Printer Connection, Remote PC Operations
