2.23 Real-Time Clock (RTC)
Zynq Ultrascale+ devices include an internal real-time clock. The internal RTC can be accessed by the plat-
form management unit (PMU) - more information on the PMU is available in the Zynq UltraScale+ MPSoC
Technical Reference Manual [19].
The RTC crystal pad input and crystal pad output are connected on the Mercury+ XU1 SoC module to a
32.768 kHz oscillator.
Starting with revision 2 modules, a 1.2 V LDO is used to generate the battery voltage for the built-in RTC
(supplied to VCC_PSBATT pin), based on the VCC_BAT voltage mapped to the module connector. This pin
can be connected directly to a 3 V battery on the base board. Please refer to the Enclustra Module Pin
Connection Guidelines [11] for details.
On revision 1 modules, the battery voltage is generated using a voltage divider.
An external RTC (separate chip, not within the MPSoC) may be assembled optionally on the Mercury+ XU1
SoC module.
2.24 Secure EEPROM
The secure EEPROM is used to store the module type and serial number, as well as the Ethernet MAC address
and other information. It is connected to the I2C bus.
The secure EEPROM must not be used to store user data.
Please refer to Section 4.4 for details on the content of the EEPROM.
2.24.1 EEPROM Type
Table 34 describes the equipped EEPROM device type on the Mercury+ XU1 SoC module.
Type Manufacturer
ATSHA204A-MAHDA-T (default) Atmel
DS28CN01 (assembly option) Maxim
Table 34: EEPROM Type
An example demonstrating how to read data from the EEPROM is included in the Mercury+ XU1 SoC module
reference design [2].
2.25 Debug Connector
The Mercury+ XU1 SoC module may optionally be equipped with a debug connector that allows the user to
perform debug operations using JTAG or TRACE signals connected to the ARM DAP, to monitor and control
FPGA configuration signals and to have access to the I2C bus and UART.
Note that starting with revision 3, the debug connector is not offered as an optional feature anymore. The
related circuitry has been completely removed, including the MIO pin mappings for PJTAG, TRACE, and
debug UART interfaces. PJTAG boot mode is also not supported any longer. The signals that were mapped
to the debug connector have been renamed to reflect the changes.
D-0000-428-001 46 / 66 Version 13, 15.08.2019
