5 Operating Conditions
5.1 Absolute Maximum Ratings
Table 49 indicates the absolute maximum ratings for Mercury+ XU1 SoC module. The values given are for
reference only; for details please refer to the Zynq UltraScale+ MPSoC, DC and AC Switching Characteristics
Datasheet [21].
Symbol Description Rating Unit
VCC_MOD Supply voltage relative to GND -0.5 to 16 V
VCC_BAT Supply voltage for MPSoC battery-backed RAM and
battery-backed RTC
0 to 3.6 V
VCC_IO_B47
Output drivers supply voltage relative to GND -0.5 to 3.4 V
VCC_IO_B48
VCC_CFG_MIO Output drivers supply voltage relative to GND -0.5 to 3.63 V
VCC_IO_B64
Output drivers supply voltage relative to GND -0.5 to 2.0 V
VCC_IO_B65
VCC_IO_B66
V_IO I/O input voltage relative to GND -0.5 to V
CCO
+0.5 V
Temperature
Temperature range for extended temperature modules (E)
*
0 to +85
◦
C
Temperature range for industrial modules (I)
*
-40 to +85
◦
C
Table 49: Absolute Maximum Ratings
D-0000-428-001 61 / 66 Version 13, 15.08.2019
