3 Device Configuration
3.1 Configuration Signals
The PS of the MPSoC needs to be configured before the FPGA logic can be used. Xilinx Zynq devices need
special boot images to boot from QSPI flash, eMMC flash or SD card. For more information, please refer to
the Zynq UltraScale+ MPSoC Technical Reference Manual [18].
Table 32 describes the most important configuration pins and their location on the module connector. These
signals allow the MPSoC to boot from QSPI flash, eMMC flash or SD card, and can be used to program the
QSPI flash from an external master. Please refer to Section 3.11 for details.
Signal MPSoC Mod. Conn.
Name Pin Type Pin Description Comments
FLASH_CLK MIO0 A-118 SPI CLK
4.7 kΩ pull-up to
VCC_CFG_MIO
FLASH_DO MIO1 A-122 SPI MISO
4.7 kΩ pull-up to
VCC_CFG_MIO
FLASH_DI MIO4 A-114 SPI MOSI
4.7 kΩ pull-up to
VCC_CFG_MIO
FLASH_CS# MIO5 A-116 SPI CS#
4.7 kΩ pull-up to
VCC_CFG_MIO
PS_DONE PS_DONE A-130 MPSoC device configuration done
1 kΩ pull-up to
VCC_CFG_MIO
PS_POR# PS_POR_B A-132 MPSoC power-on reset
4.7 kΩ pull-up to
VCC_CFG_MIO
PS_SRST# PS_SRST_B A-124 MPSoC system reset
4.7 kΩ pull-up to
VCC_CFG_MIO
BOOT_MODE0 - A-126 Boot mode selection
4.7 kΩ pull-up to
VCC_CFG_MIO
BOOT_MODE1 - A-112 Boot mode selection
4.7 kΩ pull-up to
VCC_CFG_MIO
Table 32: MPSoC Configuration Pins
D-0000-464-001 43 / 58 Version 02, 21.07.2021
