5.2 Recommended Operating Conditions
Table 44 indicates the recommended operating conditions for Mercury+ XU6 SoC module. The values
given are for reference only; for details please refer to the Zynq UltraScale+ MPSoC, DC and AC Switching
Characteristics Datasheet [20].
Symbol Description Rating Unit
VCC_MOD Supply voltage relative to GND 4.75 to 15.75 V
VCC_BAT Supply voltage for MPSoC battery-backed RAM and battery-
backed RTC
2.0 to 5.5 V
VCC_IO_[x]
Output drivers supply voltage relative to GND
Refer to
V
VCC_CFG_[x] Section 2.9.5
V_IO I/O input voltage relative to GND -0.2 to V
CCO
+0.2 V
Temperature
Temperature range for extended temperature modules (E)
*
0 to +85
◦
C
Temperature range for industrial modules (I)
*
-40 to +85
◦
C
Table 44: Recommended Operating Conditions
Warning!
*
The components used on the hardware are specified for the relevant temperature range. The user
must provide adequate cooling in order to keep the temperature of the components within the specified
range.
D-0000-464-001 54 / 58 Version 02, 21.07.2021
