Touching the capacitors of the DC-DC converters can lead to voltage peaks and permanent damage; over-
voltage on power or signal lines can also cause permanent damage to the module.
Warning!
It is possible to mount the Mercury+ XU6 SoC module the wrong way round on the base board - always
check that the mounting holes on the base board are aligned with the mounting holes of the Mercury+
XU6 SoC module.
The base board and module may be damaged if the module is mounted the wrong way round and
powered up.
1.1.6 Electrostatic Discharge
Electronic boards are sensitive to electrostatic discharge (ESD). Please ensure that the product is handled
with care and only in an ESD-protected environment.
1.1.7 Electromagnetic Compatibility
The Mercury+ XU6 SoC module is a Class A product (as defined in IEC 61000-3-2 standard) and is not
intended for use in domestic environments. The product may cause electromagnetic interference, for which
appropriate measures must be taken.
1.2 Features
• Xilinx Zynq® UltraScale+™ MPSoC
• XCZU2CG/XCZU2EG/XCZU3EG/XCZU4CG/XCZU4EV/XCZU5EV device
• SFVC784 package
• Dual-/Quad-core ARM® Cortex™-A53 MPCore™ up to 1.333 GHz
• Dual-core ARM® Cortex™-R5 MPCore™ up to 533 MHz
• Mali-400 MP2 GPU (not for CG variants)
• H.264 / H.265 Video Codec (only for EV variants)
• Xilinx 16nm FinFET+ FPGA fabric
• ZU2CG/ZU2EG/ZU3EG: 274 user I/Os
• 14 ARM peripheral I/Os (SPI, SDIO, CAN, I2C, UART)
• 240 FPGA I/Os (single-ended, differential or analog)
• 148 HP I/Os
• 144 I/Os up to 1.8V
• 4 I/Os up to 3.3V (routed via level shifters)
• 92 HD I/Os (up to 3.3 V)
• 20 GTR MGT signals (clock and data)
• ZU4CG/ZU4EV/ZU5EV: 294 user I/Os
• 14 ARM peripheral I/Os (SPI, SDIO, CAN, I2C, UART)
• 240 FPGA I/Os (single-ended, differential or analog)
• 148 HP I/Os
• 144 I/Os up to 1.8V
• 4 I/Os up to 3.3V (routed via level shifters)
• 92 HD I/Os (up to 3.3 V)
• 40 MGT signals (clock and data)
• 20 GTH MGT signals
• 20 GTR MGT signals
D-0000-464-001 7 / 58 Version 02, 21.07.2021
