3.3 Power-on Reset Delay Override
The power-on reset delay override MPSoC signal (POR_OVERRIDE) is pulled to GND on the module, setting
the PL power-on delay time to the default standard time.
If the application requires faster PL power-on delay time, this can be achieved by removing R209 component
and by mounting R208.
Figure 12 illustrates the configuration of the POR_OVERRIDE signal. Figure 13 indicates the location of the
pull-up/pull-down resistors on the module PCB - middle right part on the bottom view drawing.
For details on the POR_OVERRIDE signal please refer to the Zynq UltraScale+ MPSoC Technical Reference
Manual [18].
3.4 Boot Mode
The boot mode can be selected via two signals available on the module connector.
Table 33 describes the available boot modes on the Mercury+ XU6 SoC module.
BOOT BOOT Mode Description Remarks
MODE1 MODE0 Straps [3:0]
0 0 0110 Boot from eMMC flash -
0 1 1110 Boot from SD card (with an ex-
ternal SD 3.0 compliant level
shifter; only available when
VCC_CFG_MIO is 1.8 V)
Not supported (may be sup-
ported in the future)
1 0 0010 Boot from QSPI flash -
1 1 0101 Boot from SD card (default
mode)
-
1 0 0000 JTAG boot mode Refer to Section 3.5.3 for details.
Table 33: Boot Modes
3.5 JTAG
The Zynq Ultrascale+ devices include two separate JTAG controllers: the Zynq Ultrascale+ TAP and the ARM
DAP. The first one uses the PS dedicated JTAG pins and has access to both PS and PL and the second one
uses the PS PJTAG pins and is used for loading programs, system test, and PS debug.
Details on JTAG and on system test and debug are available in the Zynq UltraScale+ MPSoC Technical Ref-
erence Manual [18].
Certain Xilinx tool versions support QSPI flash programming via JTAG only when JTAG boot mode is used
(unavailable on the Mercury+ XU6 SoC module). Alternatively, the QSPI flash can be programmed in u-boot
or Linux by the SPI controller in the PS or from an SPI external master.
D-0000-464-001 45 / 58 Version 02, 21.07.2021
