4.4 Secure EEPROM
The secure EEPROM is used to store the module serial number and configuration. In the future, the EEPROM
will be used for copy protection and licensing features. Please contact us for further information.
An example demonstrating how to read the module information from the EEPROM memory is included in
the Mercury+ XU6 SoC module reference design.
Warning!
The secure EEPROM is for Enclustra use only. Any attempt to write data to the secure EEPROM causes
the warranty to be rendered void.
4.4.1 Memory Map
Address Length (bits) Description
0x00 32 Module serial number
0x04 32 Module product information
0x08 40 Module configuration
0x0D 24 Reserved
0x10 48 Ethernet MAC address
0x16 48 Reserved
0x1C 32 Checksum (only for DS28CN01 EEPROM type)
Table 38: EEPROM Sector 0 Memory Map
Module Serial Number
The module serial number is a unique 32-bit number that identifies the module. It is stored using big-endian
byte order (MSB on the lowest address).
Module Product Information
This field indicates the type of module and hardware revision.
Module Product Family Reserved Revision Product Information
Mercury+ XU6 SoC module 0x0337 0x[XX] 0x[YY] 0x0337 [XX][YY]
Table 39: Product Information
D-0000-464-001 50 / 58 Version 02, 21.07.2021
