Module Configuration
Addr. Bits Comment Min. Value Max. Value Comment
0x08
7-4 MPSoC type 0 5 See MPSoC type table
(Table 41)
3-0 MPSoC device speed grade 1 3
0x09
7-6 Temperature range 0 2 See temperature
range table (Table 42)
5 Power grade 0 (Normal) 1 (Low power)
4-3 Gigabit Ethernet port count 0 1
2 Reserved - -
1 DDR4 PS bandwidth 0 (Half) 1 (Full)
0 DDR4 PS ECC enabled 0 (No) 1 (Yes)
0x0A
7-2 Reserved - -
1-0 USB 2.0 port count 0 2
0x0B
7-4 DDR4 RAM (PS) size (GB) 0 (0 GB) 4 (8 GB) Resolution = 1 GB
3-0 Reserved - -
0x0C
7-4 eMMC flash size (GB) 0 (0 GB) 5 (16 GB) Resolution = 1 GB
3-0 QSPI flash memory size (MB) 0 (0 MB) 7 (64 MB) Resolution = 1 MB
Table 40: Module Configuration
The memory sizes are defined as Resolution×2
(Value-1)
(e.g. DRAM=0: not equipped, DRAM=1: 1 GB,
DRAM=2: 2 GB, DRAM=3: 4 GB, etc).
Table 41 shows the available MPSoC types.
D-0000-464-001 51 / 58 Version 02, 21.07.2021
