Diagnostics and troubleshooting Proline Promass E 100 Modbus RS485
74 Endress+Hauser
12.9 Event logbook
12.9.1 Event history
A chronological overview of the event messages that have occurred is provided in the
events list which contains a maximum of 20 message entries. This list can be displayed via
FieldCare if necessary.
Navigation path
Event list: F → Tool box→ Additional functions
For information on the event list, see the FieldCare user interface
This event history includes entries for:
• Diagnostic events → 71
• Information events → 74
In addition to the operation time of its occurrence and possible troubleshooting measures,
each event is also assigned a symbol that indicates whether the event has occurred or is
ended:
• Diagnostics event
• : Event has occurred
• : Event has ended
• Information event
: Event has occurred
To call up the measures to rectify a diagnostic event:
Via "FieldCare" operating tool → 69
For filtering the displayed event messages → 74
12.9.2 Filtering the event logbook
Using the Filter options parameter, you can define which category of event messages is
displayed in the Events list submenu.
Navigation path
"Diagnostics" menu → Event logbook → Filter options
Filter categories
• All
• Failure (F)
• Function check (C)
• Out of specification (S)
• Maintenance required (M)
• Information (I)
12.9.3 Overview of information events
Unlike a diagnostic event, an information event is displayed in the event logbook only and
not in the diagnostic list.
Information event Event text
I1000 -------- (device ok)
I1089 Power on
I1090 Configuration reset
I1091 Configuration changed
I1110 Write protection switch changed
I1111 Density adjust. error
