Proline Prosonic Flow 93T Portable Description of Device Functions
Endress+Hauser 71
11.3.3 Group SPECIAL UNITS
Function group ARBITRARY UNITS
11.4 Block QUICK SETUP
Functional description
MEASURED VARIABLES SPECIAL UNITS ARBITRARY UNIT
Use this function group to define an arbitrary unit for the flow rate variable.
TEXT ARBITRARY VOLUME
(0602)
Use this function to enter a text for the selectable volume (flow) unit. You define only
the text, the unit of time is provided from a choice of options (s, min, h, day).
User input
7-digit floating-point number
Factory setting
_ _ _ _ (No text)
Example
If your text entry is "GLAS", this text string appears on the display complete with the
unit of time, e.g. "GLAS/min":
GLAS = Volume (text input)
GLAS / min = Volume flow as shown (on the display)
FACTOR ARBITRARY
VOLUME
(0603)
Use this function to define a quantity factor (without time) for the free selectable unit.
The volume unit on which this factor is based is one liter.
User input
xxxxxxx (max. 4 characters)
Valid characters are A–Z, 0–9, +, –, decimal point, white space or underscore
Factory setting
1
Reference quantity
Liter
Example
The volume of a glass is 0.5 l 2 glasses = 1 liter
User input: 2
Functional description
QUICK SETUP
Description of the procedure and illustration of the subsequent Quick Setups  ä 41 ff.
QUICK SETUP SENSOR
INSTALLATION
(1001)
Use this function to start the Setup menu for sensor installation.
Options
YES
NO
Factory setting
NO
QUICK SETUP
COMMISSIONING
(1002)
Use this function to start the Setup menu for commissioning.
Options
YES
NO
Factory setting
NO
QUICK SETUP PULSATING
FLOW
Use this function to start the Setup menu for commissioning.
Options
YES
NO
Factory setting
NO
