INITIALIZATION
8.5.1.1 Configuration of Load Management Module
> For correct communication some parameters are set at the measuring module. Information
about the procedure can be found in the manual of the model EEM-MA370-R by the manu-
facturer Phoenix-Contact under the following link
http://www.phoenixcontact.com
• Connect the load management module and the charger via Ethernet-RJ45 (CAT6).
• To change the IP address enter the PIN code "0100"
• Set the IP address statically to 192.168.111.90
• Activate the setting "Modbus TCP" under System in the measuring module's settings
• Set the transformer type and ratio:
to do this, see the manual of the measuring module EEM-MA370-R
• Check the currently recorded, displayed power on the display of the measuring module.
>
All further settings are made by EnerCharge.
In order to make all necessary settings, section 8 in the document
"Form F50" must be lled out.
G INFORMATION
