6 Configuring the Thermostat Settings
To configure the thermostat to match your HVAC configuration:
For Foundation thermostats, go to the Installer Setup and Equipment Settings menus.
For Pioneer Z100 thermostats, go to the Setup menu.
If required, use the password to access the additional menu items listed below. The default password is “INST”.
For settings for specific equipment types and configurations, see the information under 7 Standard Configurations.
6.1 Conventional Settings
Select the type of equipment (Conventional or Heat Pump), the
default is Conventional.
Select the number of cool stages from 0 to 2.
The default is 1.
Select the number of heat stages from 0 to 2 (3 for heat pumps).
The default is 1.
Select the minimum on/off time from 1 to 10 minutes.
The default is 3.
Note: A minimum of 2 minutes is recommended for a furnace and
3 minutes for heat pumps and air conditioners.
Set to Yes if the thermostat controls the fan (common in electric
furnaces).
Set to No if the furnace controls the fan (common in gas furnaces).
The default is Yes.
