The first Pager Link Info screen displays the current status of the pager module’s connection to the network:
Foundation is connected to the pager network,
successfully provisioned and receiving messages.
The pager module is working but is unable to
detect the pager network.
Contact Technical Support. See 15 Energate
Technical Support.
The pager module is working and was previously
connected to the network, but is no longer
communicating with the network.
Contact Technical Support. See 15 Energate
Technical Support.
There is a problem with the pager module
related to its hardware or configuration. For
example, the installed module is not supported,
cannot be enabled, or has reset itself.
Contact Technical Support. See 15 Energate
Technical Support.
The pager module is working, has detected the
pager network, and is waiting to be provisioned.
For information on provisioning the pager
module, see 11.3 Provisioning the Pager.
The pager module is connected to the pager
network but is waiting for a beacon signal from
the network. Foundation cannot be provisioned
until it receives the beacon signal.
For information on provisioning the pager
module, see 11.3 Provisioning the Pager.
For more information on troubleshooting, see 12.6 Troubleshoot the Pager Module Installation and Provisioning.
9.8 Wi-Fi Module
The Wi-Fi Module enables wireless, two-way communication with your utility through a Wi-Fi network. It can be used
with any Energate Foundation 1.3 thermostat (Firmware v3.4). The Wi-Fi module acts as an alternative to the ZIP
Connect IP-ZigBee gateway and allows the Foundation thermostat to act as an IP-ZigBee gateway for other Energate
devices. The Wi-Fi module can also be used as an alternate communication path when the Foundation is joined to a
ZigBee meter to enable the Consumer Portal.
9.8.1 Installation
The Wi-Fi module is similar to the pager module in size and shape and can be physically attached to the thermostat
using the same steps described for the pager module in section 9.7.1 Installation.
Note: After the Wi-Fi module has been correctly attached, the Wi-Fi option should become available in the Installer
Setup menu.
9.8.2 Connecting the Foundation Thermostat to the Wireless Network
To connect the Foundation thermostat to the Wi-Fi network:
1. From the thermostat main menu, navigate to the Installer Setup menu. Select the Wi-Fi option from the
installer setup and select Configure Wi-Fi.
2. Read the instructions that show up on the thermostat screen and press the select button to proceed.
3. The thermostat should ask if you want to start ADHOC mode, scroll to yes and press the select button.
