10.2 Heat-Pump System Test
Use temporary hold to bypass delays associated with the minimum on or off times.
Fan
Mode = OFF
Fan = change from AUTO to ON
Fan should turn on
1
ST
stage cooling
Mode = COOL
Set the setpoint to at least 3°F (2°C) below
room temperature, and then press ACCEPT to
engage HOLD.
First stage cooling should
engage
2
ND
stage cooling*
Remain in COOL mode, lower setpoint by at
least one degree (°F or °C), and then press
ACCEPT again.
Second stage cooling
should engage
1
ST
stage heating
Mode = HEAT
Set the setpoint by at least 3°F (2°C) above
room temperature, and then press ACCEPT
First stage heating should
engage
2
ND
stage heating*
Remain in HEAT mode, raise setpoint by at least
one degree (°F or °C), and then press ACCEPT
again.
Second stage heating
should engage.
Heating using
Auxiliary Heat**
Remain in HEAT mode, raise setpoint by at least
one degree (°F or °C), and then press ACCEPT
again.
Auxiliary heating should
engage (if there are more
heat stages than cool
stages)
* Only in two stage heat pump systems.
** Only with Heat-Pump systems equipped with an Auxiliary Heater
Output tested
Procedure
Expected Result
