Installation and Operation Manual - DustEx Installation
Doc.-ID: COM_OXI_Dust_11022020 7
2.3 Access to the Terminals
Warning
Before removing the terminal covers, switch off the mains voltage to the system. Switch the mains
voltage on only after attaching the terminal cover. After the installation has been completed, live parts
may no longer be accessible.
Figure 5 -
Access to the Terminals
To connect the wires, follow step 1 to 3.
Figure 6 - Instruction for the connection of the terminals
2.4 Fitting of Ferrite Sleeves
In order to avoid cable related disturbances to the electronic unit, the supplied ferrite sleeves are to be fitted.
CE-conformity is invalid, if these ferrite sleeves are not fitted!
