DustEx Technical Data
Doc.-ID: COM_OXI_Dust_11022020 23
A Technical Data
A.1 Electronic Unit
Housing:
sheet steel powder coated;
RAL6029 (GRP version optional)
(SME-57, 19” rack optional)
IP Code:
Safe Area Housing: IP66
GFK cabinet: IP66
19“ housing: IP20
Display:
LC Dot Matrix 240 x 64 - LED backlit
Keypad:
membrane keypad
Signal LEDs:
orange: alarm, orange: maintenance, red: error
O
2
measuring ranges:
2 ranges, freely configurable from 0 % - 2 % O
2
to 0 % - 25
% O
2
, other O
2
measuring ranges on request
Accuracy:
< 0.5 % of measured value or 0.02 Vol % O2 (higher value
valid)
COe measuring range (COMTEC):
1 range, min.: 0-1000 ppm / max.: 0-10000 ppm (factory
adjustable, other ranges on request)
COe accuracy: (COMTEC)
better 5% of range end
Manual or ACAL
(Automatic calibration):
1 or 2 point (automatic calibration)
Mains Voltage:
230 V AC ±10 % 50 Hz to 60 Hz
115 V AC ±10 % 50 Hz to 60 Hz
Power consumption:
225 VA (typical measuring mode)
425 VA (heating phase)
Recommended fuse:
10 A
Output signal:
O
2 - active, 0/4 to 20 mA
max. load 500 Ω
CO
e -
active, 4 to 20 mA
max. load 500 Ω
Relay contact:
24 V AC/DC, 1 A
Relay contact solenoid valve:
230 V AC/DC, 1 A
Dimensions:
300 x 440 x 240 mm (W x H x D) (standard field housing)
483 x 177 x 400 mm (W x H x D) (19” rack)
Weight:
approx. 20kg
approx. 12 kg (19” rack)
Temperature range - storage:
-40 °C to +80 °C (-40 °F to 176 °F)
Temperature range - operation:
-20 °C to +55 °C (-4 °F to 129 °F), others on request
