Enotec COMTEC 6000 DustEx - Display Board

Spare Parts Installation and Operation Manual - COMTEC
®
/ OXITEC
®
DustEx
32 Doc.-ID: COM_OXI_Dust_11022020
Figure 53 - Mounting plate 2 with HCU and COe sensor board (COMTEC only)
Parts List - Mounting plate 2
HCU-0001 Failsafe heater control
0-L-000180 Power board
0-A-000155 Mounting plate
Terminal block X10
0-L-000107 COe sensor board (Rear side of mounting plate, COMTEC only)
Info
The spare parts used in SME54 19" racks are identical to the spare parts shown above.
C.2 Display Board
Figure 54 - Display-board
Parts List - Display Board
0-L-000035+
SME5 OXITEC display board without
pneumatic
0-L-000036+ SME5 OXITEC display board with pneumatic
0-L-000108+
SME5 OXITEC display board, CSP with
pneumatic
0-L-000110+
SME5 OXITEC display board, RS232 with
pneumatic
0-L-000102+ COMTEC display board with software
