Error Messages
ERROR MESSAGES
Occasional error messages are not unusual, and unless they become chronic, they are not a cause for
concern. It is important to realize that these messages are diagnostics and do not necessarily indicate a
problem. These messages were designed to help our software engineers in the development of the
software, not as hardware diagnostics.
Software Messages
The following error messages could be caused by software:
IDnU Descrintion
ID# Desctiution
013 software error in voice assignments
132 chk instruction register out of bounds
016 poly or mono pressure events sent to VC
133 trapv instruction ovefflow error
020 unknown button event
134 privilege violation
048 parameter error
135 trace
049 layer error
137 line 1111 emulator
080 bad buffer to MIDI
138 spurious interrupt
128 bus error
139 unused vector
129 odd address error
192 load all data error (from MIDI or card)
130 divide by zero
193 keyup playback error
13 1 llegal instruction
194 out of SDBs error
Digital Board Problems
The following error messages could be caused by a problem on the digital board:
005 could not synchronize audio input
033 bad ESP chip
006 could not synchronize audio input
034 bad ESPFWM
019 Bad OTTO interrupt
040* bad ESP error
032 bad download 145 unknown DUART interrupt error
Analog or Digital Board Problem (clock comes from analog board, make sure there are no analog
fuses blown and that the analog power supplies are O.K.)
009 No LRCLK input to 68302
MIDI or Main Board Problems
The following error is usually caused by too much incoming MIDI data. It also could be caused by a
problem with the keyboard.
144 out of buffers
Disk File Operation Errors
The following error messages could be caused by software:
ID# DescriDtion
ID# Descrintion
00 illegal block # during read/write
07
current DIR & FAT info in buffer is not valid
01 Missing End of File marker 08 not enough space to save file
02 Premature End of File marker 10 file size > free blocks on device
03 file linked list points to unused block 15 no free blocks found on the diskette
04 file linked list points to bad block 16 illegal fat block # load was attempted
ASR Service Manual
23
