Envipco FLEX Series - Power Requirements; Operating the FLEX; Usage

Chapter 2
Specifications
2
-
4
2.1.4. Power Requirements
Table 2-2 shows the power requirements by RVM model. All models receive single-phase power
from the outlet, regardless of whether the outlet is three-phase or single-phase.
TABLE 2-2 RVM Power Requirements
Product Voltage (VAC) Amperage (A) Frequency (Hz)
FLEX Can/PET RVM
208/240V 1-phase 10 50
FLEX Can /PET/ Glass Soft Drop
RVM
208/240V 1-phase 10 50
FLEX HDS Can/PET RVM 208/240V 1-phase 16 50
2.2. Operating the FLEX
The FLEX is easy to use. The display gives instructions and recycling information to the customer.
The display screen changes color: It is green when the machine is ready to accept containers and
red when the customer should not insert containers.
2.2.1. Usage
When a customer approaches the machine with a used beverage container:
1. The customer places the container into the In-Feed with the bar code facing upwards.
2. The conveyor moves the container into the machine.
3. As the container passes below the scanners, the scanners read the bar code.
4. While moving along the conveyor belts, a PET sensor determines if the
container is PET plastic, and a metal sensor determines if the container is an
aluminum or steel can.
5. If the RVM rejects the container, the conveyor reverses to return the
container to the customer. It displays a message instructing the customer to
remove the container and gives the reason for rejection. The following are
reasons for rejection:
•
••
• The FLEX does not accept that type of container. For example, a
machine that only accepts PET will not accept glass.
•
••
• The scanner cannot read the bar code, because the container is damaged
or does not have a bar code.
•
••
• The bar code is readable but not in the RVM’s database of acceptable
containers.
•
••
• If the user inserted more than one container at a time, the RVM rejects
the containers.
