4.4.5. RS-485 Tab
The RS-485 tab contains the Hardware Process options. The Multidrop Bus (MDB) uses the RS-485
serial protocol. On the MDB, each client board (MC1 and MC5) has a hexadecimal number assigned
to it. This tab allows you to Detect Clients, Get Client List, Re-Initialize a Client, Reconnect
the Multidrop Bus Port, and to send commands to the bus. This tab is shown in Figure 4-12.
FIGURE 4-12. Diagnostics - RS-485 Tab
