Envipco FLEX Series - Printer; Video Display

Chapter 3
Hard
w
ar
e
Components
3
-
20
Printer
The FLEX has a Hecon X56 thermal printer with cutter. It prints payment receipts and may be
configured to print coupons.
FIGURE 3-20. Printer Assembly
Video Display
The display is a 10.4 inch VGA monitor with touch screen. When the machine is ready to accept
containers, it gives instructions to the user. The RVM may also be configured to play video clips for
the users. When the machine is in service mode, the technician can use the display to use the
Diagnostic Program, fix errors, and upload and download files.
Payment Button
Hecon X56 Printer
Print Head Lift Pin
Printer Cover
Receipt Chute
