Epec 5050 - Connection Examples for Pwm;Do;Di_Type006

5050 CONTROL UNIT
Technical Manual & Cabling Instructions
47 / 92
19.10.2012
5050 / MAN000539
Epec Oy reserves all rights for improvements without prior notice
Epec Oy Postiosoite/Postal address Puhelin/Phone Fax Internet
Tiedekatu 6 PL/P.O.Box 194 +358-(0)20-7608 111 +358-(0)20-7608 110 www.epec.fi
FIN-60320 Seinäjoki FIN-60101 Seinäjoki, Finland
4.7.5 Connection Examples for PWM/DO/DI_Type006
The following figures show examples on how to connect some external actuators when using
the PWM/DO/DI_Type006 pin:
