Epec 5050 User Manual

5050 CONTROL UNIT
Technical Manual & Cabling Instructions
10 / 92
19.10.2012
5050 / MAN000539
Epec Oy reserves all rights for improvements without prior notice
Epec Oy Postiosoite/Postal address Puhelin/Phone Fax Internet
Tiedekatu 6 PL/P.O.Box 194 +358-(0)20-7608 111 +358-(0)20-7608 110 www.epec.fi
FIN-60320 Seinäjoki FIN-60101 Seinäjoki, Finland
3 TECHNICAL DATA
Processor
32-bit CPU, 128 MHz
Memory
Flash 8 MByte
RAM 4 MByte (1 MByte for PLCopen application)
NVRAM 512 kbyte (for error logs, system parameters)
Power
Nominal supply voltage 12/24 V systems (8,3 ... 36 V),
Idle power consumption 2,2 W
Undervoltage reset 7,5 V
Overvoltage protection typical 43 VDC
REF voltage outputs
+5 V, +10 V
Diagnostics
Signal LED (green/red)
Temperature monitoring
Error logging
Programming
CoDeSys 2.3, Application size 1 MByte
Software installation
Download to flash memory via CAN1 or Ethernet
Protection class
IP67
Size / Outer dimensions
224,8 x 148,5 x 50 mm
8.819 x 5.827 x 1.969 in
Weight
0,95 kg
2.09 lbs
Case material
Aluminium / plastic
Operating temperature
-40... +85°C
-40...+185°F
Storage temperature
-40... +85°C
-40...+185°F
Connectors
3 x AMP35
Communications/ Interfaces
4 x CAN 2.0 B,
1 x Ethernet
I/O pins total
65

Epec 5050 Specifications

General

Brand	Epec
Model	5050
Category	Control Unit
Language	English
