Electrical fast transient (EFT/B) immunity test
• Test method EN 61000-4-4
• Performance criterion B
Test pulse Port Test
level
5 (Tr) / 50 (Th)
ns, repetition
frequency 5 kHz,
duration 5
minute
DC input
port
± 2,0 kVp
Signal
port
± 1,0 kVp
Electrostatic discharge (ESD) immunity test
• Test method EN61000-4-2
• Performance criterion B
Discharge mode
Test level (kVp)
Contact
± 2, ± 4, ± 6
Indirect contact
± 2, ± 4, ± 6
Air
± 2, ± 4, ± 8
Performance criteria for immunity tests
Performance criterion A:
The EUT shall continue to operate as intended during and after the test. No degradation of performance is
allowed.
Performance criterion B:
The EUT shall continue to operate as intended after the test. However, moderate degradation of
performance is allowed. No change of actual operating state or loss of memory functions is allowed.
