Name Function
I
Lens replacement
cover
Remove when attaching or removing the lens.
s "Removing and Attaching the Projector Lens Unit"
p.27
Caution
When moving the projector, do not hold the lens
replacement cover. The lens replacement cover
may be removed and the projector may fall, which
could cause an injury.
J
Air exhaust vent
Exhaust vent for air used to cool the projector internally.
Caution
While projecting, do not put your face or hands
near the air exhaust vent, and do not place objects
that may become warped or damaged by heat near
the vent. Hot air from the air exhaust vent could
cause burns, warping, or accidents to occur.
Rear
Name Function
A
Power inlet
Connects the power cord to the projector.
B
Control panel
s "Control Panel" p.18
C
Security slot
The security slot is compatible with the Microsaver
Security System manufactured by Kensington.
s "Anti Theft/Fall Prevention" p.119
D
Connector Ports
s "Connector Ports" p.17
Part Names and Functions
16
