Epson EB-L1075U - Displaying a Scaled Image

a
Whenever the [ ] button is pressed, the screen changes
between the projected image and the adjustment screen.
b
Select Adjustment Level, and then use the [ ][ ] buttons to set
the adjustment level.
c
Select Red, Green, or Blue, and then press the [ ][ ] buttons to
adjust the color tone.
d
Select Brightness, and then use the [ ][ ] buttons to adjust the
brightness.
e
Return to step 1 and adjust each level.
f
Press the [Esc] button to return to the previous screen.
Displaying a Scaled Image
A section of the image is cropped and displayed. This allows you to create
one large image by combining images projected from multiple projectors.
a
Project the image, and then press the [Menu] button.
b
Select Multi-Projection from Extended.
a
You can also perform the same operation from Scale in
Signal.
c
Select Scale, and then press the [ ] button.
d
Turn on Scale.
(1)
Select Scale, and then press the [
] button.
(2)
Select Auto or Manual, and then press the [
] button.
Auto: Automatically adjusts the clipped area according to the adjustment
values in Edge Blending and Tiling. You do not need to perform any steps
after step 6.
Manual: Allows you to adjust the clipped area manually.
(3) Press the [Esc] button to return to the previous screen.
Multi-Projection Function
97
