a
Select 4K Enhancement from Image Enhancement, and then
press the [
] button.
b
Select one of the following, and then press the [ ] button.
Off: Disables 4K Enhancement. If a signal that exceeds the panel
resolution of this projector is input, the image is displayed according
to the panel resolution of this projector.
Full HD: If a signal with a resolution of 1080i/1080p/WUXGA or
higher is input, 4K Enhancement is enabled.
WUXGA+: If a signal with a resolution that exceeds WUXGA is
input, 4K Enhancement is enabled. To project a high-resolution
movie, you can project a high-definition image by using this setting
with Image Preset Mode.
a
• To project from multiple projectors, select Off to unify each
image.
• Off is ideal for projecting presentation materials from
computers and so on.
• If set to Full HD or WUXGA+, the status corrected using the
following function is canceled.
Edge Blending, Scale, Curved Surface, Point Correction,
Corner Wall
When 4K Enhancement is set to Off, the settings return to
their previous state.
c
Press the [Esc] button to return to the previous screen.
Image Preset Mode
Select the optimal setting according to the projected image from five presets
prepared in advance.
The following settings are saved in the presets.
Frame Interpolation, Deinterlacing, Noise Reduction, MPEG Noise
Reduction, Super-resolution, Detail Enhancement
a
• To minimize delays, set Image Preset Mode to Off.
• If you set Image Preset Mode to Off, you cannot set the other items
in Image Enhancement.
a
Select Image Preset Mode from Image Enhancement, and then
press the [
] button.
b
Select one of the following, and then press the [ ] button.
Preset 1 to Preset 5: The settings saved in advance are applied to the
image.
Off: Select this to turn off presets.
Adjusting the Projected Images
