Name Function
D
[ ] button
• When the Configuration menu or the Help screen is
displayed, it accepts and enters the current selection and
moves to the next level.
• If pressed while projecting analog RGB signals from the
Computer port or the BNC port, you can automatically
optimize Tracking, Sync., and Position.
E
[ ]/[ ] buttons
• Displays the Control Panel Lock screen allowing you to
make settings to lock the control panel buttons.
s
"Restricting Operation" p.117
• If pressed when the Configuration menu or the Help
screen is displayed, this button selects menu items and
setting values.
s "Configuration Menu Operations" p.136
s "Using the Help" p.173
F
[ ]/[ ] buttons
• Displays a test pattern.
s "Displaying the Test Pattern" p.33
• If pressed when the Configuration menu or the Help
screen is displayed, this button selects menu items and
setting values.
s "Configuration Menu Operations" p.136
s "Using the Help" p.173
G
[A/V Mute] button
Turns the video and audio on or off.
s "Hiding the Image and Sound Temporarily (A/V
Mute)" p.102
H
[Lens] button
Displays the adjustment screens for lens shift, zoom,
focus, and distortion in that order each time the button is
pressed.
If pressed for more than three seconds, the lens position
moves to the home position.
Name Function
I
[ ]/[ ] buttons
• Displays the Info menu from the Configuration menu.
s "Info Menu (Display Only)" p.161
• If pressed when the Configuration menu or the Help
screen is displayed, this button selects menu items and
setting values.
s "Configuration Menu Operations" p.136
s "Using the Help" p.173
J
[ ]/[ ] buttons
• Performs screen adjustments using the settings in
Geometry Correction from the Configuration menu.
s Settings - Geometry Correction p.143
• If pressed when the Configuration menu or the Help
screen is displayed, this button selects menu items and
setting values.
s "Configuration Menu Operations" p.136
s "Using the Help" p.173
K
[Esc] button
• Stops the current function.
• If pressed when the Configuration menu is displayed, it
moves to the previous menu level.
s "Configuration Menu Operations" p.136
L
[t] button
Turns the projector off.
Part Names and Functions
19
