• Change the audio output from Audio Settings.

s Extended - A/V Settings - Audio Settings p.146

• If audio is not sent using an HDMI cable, connect a commercially available audio cable to the Audio3 port to send the audio. Set HDMI Audio Output to

Audio3.

s Extended - A/V Settings - Audio Settings - HDMI Audio Output p.146
