When projecting to a wide screen from multiple projectors, you can adjust
the difference of brightness and color tone between each projected image to
create a seamless screen.
There are two general methods of projecting from multiple projectors.
U Projecting different images from each projector, and creating a seamless screen
V Projecting the same image from each projector, using the Scale function to
project a large image
Preparation Flow
Here is an example of using U. (The basic flow is the same with V method,
but use the scale function to adjust the position of the projected image
s p.157)
1. Setting the projector ID and the remote control ID
2. Adjusting the position of the projected image
3. Checking the Color Mode
4. Using the edge blending function
5. Adjusting to match colors
Settings are explained here using the remote control, but they can also be
set by the control panel.
Projector ID/Remote Control ID
When an ID is set for the projector and the remote control, you can use
the remote control to operate only the projector with a matching ID. This
is very useful when managing multiple projectors.
When operating all of the projectors from the remote control, set the ID
switch on the side of the remote control to Off.
q
• Operation using the remote control is possible only for projectors
that are within the operating range of the remote control.
s "Operating range of remote control" p.18
• When Remote Control Type is set to Simple from Operation in the
configuration menu, you cannot set the remote control ID.
s p.57
• IDs are ignored when the projector ID is set to Off or the remote
control ID is set to 0.
Settings for Multiple Projectors
150
