E
Repeat procedures 3 and 4 as needed to adjust any remaining
corners.
F
When you are done, press the [Esc] button to exit the
correction menu.
Because the correction method was changed to Quick Corner from
Geometric Correction in the configuration menu, when [
w/ ],
[
v/ ], [</ ], and [>/ ] buttons are pressed later, the screen for
selecting the corner in procedure 2 is displayed. Change Geometric
Correction from the configuration menu to H/V-Keystone if you
want to correct H/V-Keystone when pressing the [
w/ ], [v/ ],
[
</ ], and [>/ ] buttons on the control panel. s p.55
q
If the [Esc] button is held down for about two seconds while
correcting with Quick Corner, the confirm default reset screen is
displayed.
Select "Yes" to reset the result of Quick Corner corrections.
H/V-Keystone
Procedure
Press the [
w
/ ], [
v
/ ], [
<
/ ], and [
>
/ ] buttons on the control
panel to adjust keystone settings in the horizontal and vertical
directions independently.
q
This adjustment can also be made from Geometric Correction -
H/V-Keystone on the Settings menu. s p.55
• Correcting vertical keystone
Vertical keystone can be corrected to a vertical projector tilt of up to 30˚
against the screen.
If the [w/ ] and [v/ ] buttons are pressed simultaneously for at least
1 second, the value of horizontal keystone will return to the original
status.
Adjusting the Projected Image
142
