Name Function
L
[Auto] button
If pressed during projection of computer analog RGB
signals, it automatically adjusts the Tracking, Sync., and
Position to project the optimum image.
M
[Aspect] button
The
Aspect Ratio
g
changes each time the button is
pressed. s p.22
N
[Lens Shift] button
Press to adjust the lens shift. s p.138
O
[ID] button
Press to set the remote control ID. s p.150
P
[Help] button
Displays and closes the Help screen which shows you how
to deal with problems if they occur. s p.81
Q
Remote port
Connects the optional remote control cable set and
outputs signals from the remote control. When the remote
control cable is plugged into this remote port, the remote
receiver is disabled.
R
[Default] button
Reset to default the setting values being adjusted in some
configuration menus.
S
[Zoom] button
Press to adjust the zoom. s Quick Start Guide
T
[Num] button
Use this button to enter passwords, IP Address from the
Network, and so on. s p.38
U
[Focus] button
Press to adjust the focus. We recommend setting the focus,
zoom, and lens shift at least 30 minutes after you start the
projection, because images are not stable right after
turning on the projector. s Quick Start Guide
V
Numeric buttons
Use this button to enter passwords, remote control ID
settings, IP Address from the Network, and so on.
s p.152, p.38
W
[Color Mode] button
Each time the button is pressed, the Color Mode changes.
s p.28
X
[Freeze] button
Images are paused or unpaused. s p.33
Y
[E-Zoom] buttons
[z][x]
The [z] button enlarges the image without changing the
projection size.
The [x] button reduces the parts of images that have been
enlarged using the [z] button. s p.34
Name Function
Z
[Pointer] button
Press to activate the on screen pointer. s p.34
a
[Esc] button
Stops the current function. If pressed when the
configuration menu is displayed, it moves to the previous
menu level. s p.47
Acts as a mouse's right button when using the optional
wireless mouse receiver.
b
[User] button
Press to assign a frequently used item from the available
configuration menu items. By pressing the button the
assigned menu item selection/adjustment screen is
displayed, allowing you to make one-touch settings/
adjustments. s p.55
Test Pattern is assigned as the default setting.
c
[SDI] button
Changes to images from the SDI input port. s p.21
This button does not function when using EB-Z8355W/
Z8350W/Z10005/Z10000/Z8150.
d
ID switch
Use this switch to enable (On)/disable (Off) ID settings for
the remote control. s p.150
e
[HDMI 1/2] button
Each time the button is pressed, the image displayed
changes between the HDMI1 input port and HDMI2
input port.
s
p.21
f
[Search] button
Changes to the next input source that is connected to the
projector and is sending an image. s p.20
g
Indicators
A light is emitted when outputting remote control signals.
h
Remote control light-
emitting area
Outputs remote control signals.
Installing the batteries
The batteries are not set in the remote control when it is sold. Set the
supplied batteries (two, AA alkaline batteries) to use the remote control.
Part Names and Functions
16
