Prepare #2 plus-driver in advance.
Removing and Attaching the Projector Lens Unit
Removing
Attention
•
Only remove the lens unit when necessary. If dust or dirt enter the projector,
projection quality deteriorates and it could cause a malfunction.
•
Try not to touch the lens section with your hand or fingers.
If fingerprints or oils are left on the surface of the lens, projection quality
deteriorates.
•
If the lens shift has been done, set the lens shift to the center before replacing
the lens unit.
s
p.138
Procedure
A
Remove the interface cover.
A
Loosen the fixing screw.
B
While pulling up the interface cover open switch, pull the interface cover
straight out.
B
Remove the front cover.
Installing Optional and Supplied Accessories
162
To Next Page
