Maintenance 6. Alarm
RC700 / RC700-A Rev.23 141
6.1.3 How to Edit the Alarm Information
The configured alarm information can be edited in the EPSON RC+ 7.0.
(1) Select EPSON RC+ 7.0 menu-[Tools]-[Maintenance] to display the [Controller
Tools] dialog box.
(2) Select the alarm to be changed and click the <Change> button.
(3) Display the [Change Alarm] dialog box and enter any of the followings.
Purchase or replacement date of the battery
Date of grease up
(4) Click the <OK> button and change the specified alarm information.
6.1.4 Alarm Notifying Method
The alarm notifying method needs to be configured by the output bit of the Remote I/O.
The Remote I/O can be configured in the EPSON RC+ 7.0- [Setup] - [System
Configuration] - [Controller] - [Remote Control].
For details, refer to the EPSON RC+ 7.0 User’s Guide 12.1 Remote I/O.
The controller does not enter the error or warning state even if an alarm occurs.
