Epson RC700-A User Manual

Setup & Operation 7. LAN (Ethernet Communication) Port
48 RC700 / RC700-A Rev.23
7.4 Connection of Development PC and Controller with
Ethernet
Connection between the development PC and the Controller is shown below.
(1) Connect the development PC and the Controller using the Ethernet cable.
(2) Turn on the Controller.
(3) Start EPSON RC+ 7.0.
(4) Display the [PC to Controller Communication] dialog from [Setup] in EPSON RC+
7.0 menu.
(5) Click the <Add> button.
(6) Connection “No.2” is added. Set the following and click the <Apply> button.
Name : Valid value to identify the controller to connect
IP Address : IP address for Controller to connect
(7) [Name] and [IP Address] specified in procedure (6) is displayed.

Epson RC700-A Specifications

General

Brand	Epson
Model	RC700-A
Category	Controller
Language	English
