Epson RC700-A User Manual

Setup & Operation 14. Option Slots
86 RC700 / RC700-A Rev.23
14.2.6 Pin Assignments (Expansion I/O Board)
Pin Assignment table of the 1st Expansion I/O board.
Connector 1 Pin Assignments
Pin
No.
Signal Name
Pin
No.
Signal Name
Pin
No.
Signal Name
1 Input common No.64 to 71 18 Input common No.72 to 79 34 Input common No.80 to 87
2
Input No.64
19
Input No.72
35
Input No.80
3 Input No.65 20 Input No.73 36 Input No.81
4 Input No.66 21 Input No.74 37 Input No.82
5
Input No.67
22
Input No.75
38
Input No.83
6 Input No.68 23 Input No.76 39 Input No.84
7 Input No.69 24 Input No.77 40 Input No.85
8
Input No.70
25
Input No.78
41
Input No.86
9
Input No.71
26
Input No.79
42
Input No.87
10
Output No.64
27
Output No.70
43
Output No.75
11
Output No.65
28
Output No.71
44
Output No.76
12
Output No.66
29
Output No.72
45
Output No.77
13
Output No.67
30
Output No.73
46
Output No.78
14
Output No.68
31
Output No.74
47
Output No.79
15
Output No.69
32
Not Used
48
Not Used
16
Not Used
33
Output common No.72 to 79
49
Not Used
17
Output common No.64 to 71
50
Not Used
Connector
Standard
I/O Connector (Controller side)
D-sub 50 male pin
Mounting style #4 - 40
* The I/O connector, I/O connector cable, terminal block, and I/O connector kit are offered as options.
