2. Installation
RC700 / RC90 Option Fieldbus I/O Rev.14 147
28. Select [File]-[Download in Flash] from the applicomIOR console menu. Register the
configuration to the Fieldbus master board.
Make sure that the flash memory of Fieldbus master board stores the configuration;
otherwise, the Fieldbus master board cannot function correctly. Also, you cannot
control it from EPSON RC+7.0.
If you changed the configuration, select [File]-[Download in Flash] from the
applicomIOR console menu and register the configuration to the Fieldbus master
board.
29. After a few seconds, the display of “Configured boards state” on the status bar turns
to green.
Now, the Fieldbus master board is ready to operate in the master mode.
30. Close the “applicomIO Console” application.
31. Refer to the next section EPSON RC+7.0 Configuration and continue the step.

NOTE
