2. Installation
154 RC700 / RC90 Option Fieldbus I/O Rev.14
Specifications
EtherNet/IP Scanner
Item
Specification
Name
EtherNet/IP board manufactured by Hilscher
Maximum number of EtherNet/IP
connections
64 connections for implicit and explicit
Maximum number of total cyclic
input data
5712 bytes
Maximum number of total cyclic
output data
5760 bytes
Maximum number of cyclic input
data
128 bytes per slave per telegram
Maximum number of cyclic output
data
128 bytes per slave per telegram
IO connection type
Cyclic, minimum 1 ms (depending on used
number of connections and used number of
input and output data)
Maximum number of unscheduled
data
1400 bytes per telegram
UCMM, Class 3
Supported
Explicit Messages, Client and Server
Services
Get_Attribute_Single/All
Set_Attribute_Single/All
Quick connect
Supported
Predefined standard objects
Identity Object
Message Route Object
Assembly Object
Connection Manager
Ethernet Link Object
TCP/IP Object
DLR Object
QoS Object
Maximal number of user specific
objects
20
Network scan
Supported
Topology
Tree, Line, Ring
DLR (Device Level Ring)
Beacon based “Ring Node”
ACD (Address Conflict Detection)
Supported
DHCP
Supported
BOOTP
Supported
Baud rates (bps)
10M, 100 M
Data transport layer
Ethernet II, IEEE 802.3
Switch function
Integrated
Limitations
CIP Sync Services are not implemented,
TAGs are not supported.
Reference to firmware/stack version
V2.9
