Epson RC90 User Manual

2. Installation
RC700 / RC90 Option Fieldbus I/O Rev.14 187
Specifications
Item
Specification
Name
EtherNet/IP slave board
Supported Connection I/O messaging connection (Cyclic),
Explicit messaging connection
EtherNet/IP communication protocol
Baud Rates
10 M, 100 M (bps)
Transfer Distance
Standard Ethernet protocol
Cable
Standard Ethernet protocol
Mode
Slave
Interface
1 EtherNet/IP port
Max. Input data size
2048 bits (256 bytes)
Max. Output data size
2048 bits (256 bytes)
Assembly Instance Input: 100 (64h) size: Depending on I/O settings
Output: 150 (96h) size: Depending on I/O settings
Configuration: 1 size: 0
LED Description
LED state
MS
NS
OFF Power supply OFF
Power supply OFF
or IP address not configured
GRN
ON
Master connected (executing)
Online operating
Blinking
Master connected (idling)
Waiting master connection
RED
ON
Non-recoverable error
Wrong IP address (duplication)
Blinking
Recoverable error
Connection time out
GRN/RED
alternate
Self-diagnosing Self-diagnosing
LED state
LNK
ACT
OFF No link
No communication packet
reception or transmission
ON Linking
Communication packet
reception or transmission
