2. Installation
RC700 / RC90 Option Fieldbus I/O Rev.14 199
“Encapsulation Inactivity Timeout”
Fieldbus EtherNet/IP slave module supports “Encapsulation Inactivity Timeout” which is
added by EtherNet/IP standard update.
If the EtherNet/IP master device is not supported for the standard on the above, connection
will be disconnected.
You need to change the “Encapsulation Inactivity Timeout” set value of the slave on the
EtherNet/IP master device side.
For more details, refer to 2.3.3 Installing EtherNet/IP Master Board Manufactured by
molex How to Change the Set Value on the Master Side.
Electronic Information File (EDS file)
An EDS file is supplied for EtherNet/IP slave module network configuration. The file is
located in the following folder where EPSON RC+ 7.0 is installed.
\EpsonRC70\Fieldbus\EtherNet/IP
