2. Installation
RC700 / RC90 Option Fieldbus I/O Rev.14 201
Specifications
Item
Specification
Name
CC-Link Slave Board
Connection Method
Broadcast polling
Baud Rates (bps)
156 k, 625 k, 2.5 M, 5 M, 10 M (bps)
Transfer Distance
Baud Rates
Cable Length
10 M (bps)
5 M (bps)
2.5 M (bps)
625 k (bps)
156 k (bps)
100 m
160 m
400 m
900 m
1200 m
Maximum Device Number
64 units
Cable
Dedicated cable supporting CC-Link Ver.1.10
Mode
Slave
Interface
1 CC-Link V1 port
Occupied Stations
1 to 4 station(s) (Remote device station)
Master Station’s Handshake
Max. Input Data Size
384 bits (48 bytes)
Max. Output Data Size
384 bits (48 bytes)
LED Description
LED state represents the states of the fieldbus I/O board.
LED state
ERRL RED
RUN GRN
RD GRN
SD GRN
OFF
Normal operation
Device power supply
OFF
Offline
Device power supply
OFF
No data reception
Device power supply
OFF
No data transmission
Device power supply
OFF
ON
CRC error: station
Address error
Baud rate
configuration error
Normal operation Data reception Data transmission
Blinking
−
−
−
−
Setting Configure Switch
WARNING

Make sure that the power is turned OFF before installing/removing any boards
or connecting/disconnecting any cables.
Working with the power ON is
extremely hazardous and may result in electric
al shock and/or malfunction of
equipment.
Configuration of the device station is available with the station configure switch on the
CC-Link slave board.
Baud rate configuration is available with baud rate configure switch on the CC-Link board.
1. Set the station of the CC-Link slave board with the station configuration switch.
Make sure that the station does not duplicate with the other devices inside the network
at configuration.
Switches on the ×10 side are for tenths digit address value configuration. Switches on
the ×1 side are for units digit address value configuration. Stations from 1 to 62 are
available.
