2. Installation
222 RC700 / RC90 Option Fieldbus I/O Rev.14
Specifications
Item
Specification
Name
PROFINET board
Connection Method
RT (Real-Time)
Protocol
PROFINET IO
Device type
IO device
Baud Rates (bps)
100 M bps, full duplex
Maximum segment length
100 m
Cable
RJ45 with connector 100BASE-TX (Cat5)
Cycle time
2 msec
Interface
RJ45 port × 1
Input Data Size
Max. 2048 bits (256 bytes)
Output Data Size
Max. 2048 bits (256 bytes)
LED Description
LED state represents the states of the fieldbus board.
LED state
MS
CS
LNK/ACT
OFF
Power OFF or
Device is being initialized
Offline
No link or
Power OFF
GRN
ON Normal operation
Offline
IO Controller is in RUN
Linking
Blinking - -
Receiving/transmitting
communication packet
Blinking once Evaluating
Offline /
IO Controller is in STOP
-
RED
Blinking
Blinking
once
Structure Error
- Too many (Sub) Modules
- I/O size set by IO Controller
is too large.
- Structure mismatched
(No module, wrong module)
- -
Blinking
3 times
No station name has been set or
No IP address has been set
- -
Blinking
4 times
Internal error - -
