Epson RC90 User Manual

2. Installation
RC700 / RC90 Option Fieldbus I/O Rev.14 229
Setting Configure Switch
The PROFINET module requires no configurations.
All the PROFINET communication configurations are set by the development software
(EPSON RC+ 7.0).
Wiring
PROFINET connector is RJ45 connector. Use 100BASE-TX (STP type) cable.
CAUTION

Be sure to use cables and connectors complying with the
industrial standards or
noise resistant Ethernet cable (STP cable). If you use an office use product or
UTP cable, it may cause communication errors and may not offer the proper
performance.
Installing Module
WARNING

Make sure that the power is turned OFF before installing/removing any
modules
or connecting/disconnecting any cables. Working with the power ON is
extremely hazardous and may result in electrical shock and/or malfunction of
equipment.
Install the module to the dedicated slot on the T/VT series Manipulator.
Reference: Manipulator manual Setup & Operation 17. Fieldbus I/O
